Cleaning out the barrels on HMS Nelson
in 1930
The cleaning device is a pisaba brush
RAF Museum Photograph
Rodney firing a five gun salvo
The flat, uncluttered roofs of these turrets
was a significant change from previous designs
Overhead view of HMS Nelson showing the
all-forward main battery and the port-side secondary
battery
IWM photograph Q 70606
Well-known photograph of the interior of
one the turrets on HMS Rodney
The object being handled is the gun lock
IWM Photograph A 2123
Another view of the interior of one of
the turrets on HMS Rodney
Note that the guns are not separated by
flash walls
IWM photograph A 15453
Page History
28 December 2013 - New datapage
