Port 10.5 cm/65 twin mounting on Admiral Graf Spee
At lower right is a 15 cm/55 mounting, a photograph of which may be found here
Photograph taken on 2 February 1940 by Ensign Richard D. Sampson, USN
U.S. Naval Historical Center Photograph # NH 50959

Starboard 10.5 cm/65 mounting on Admiral Graf Spee
Note the 2 cm mounting in the foreground
Photograph taken on 2 February 1940 by Ensign Richard D. Sampson, USN
U.S. Naval Historical Center Photograph # NH 50959

10.5 cm/65 SK C/33
U.S. Navy Photograph taken on Prinz Eugen while at the Philadelphia Naval Shipyard (PNSY), Pennsylvania, USA

10.5 cm (4.1") ammunition racks on Tirpitz
U.S. National Historical Center Photograph # NH 71386

Fuze-setting mechanism for 10.5 cm SK C/32 mounting
There was one of these devices on each side of the twin mounting
Bundesarchiv Photograph

Replacing a 10.5 cm gun on port No. 3 mounting aboard Admiral Hipper

German Model of 10.5 cm/65 SK C/33 na in 10.5cm Dopp L C/37 mount now at the Imperial War Museum
IWM Photograph MOD 319

French Guichen (ex-Italian Scipione Africano) in 1956
Photograph copyrighted by L & L van Ginderen

24 November 2006 - Benchmark
20 May 2012 - Updated to latest template
15 December 2013 - Added photograph of 10.5 cm model
