jiaming 发表于 2012-5-24 14:15
谢谢！不过多出来这四门100毫米火炮，会不会武器超重啊！
Chile Saumarez, Chilel Navy War Emergency Destroyer laid down 1910
Displacement:
1,593 t light; 1,673 t standard; 1,882 t normal; 2,049 t full load
Dimensions: Length (overall / waterline) x beam x draught (normal/deep)
(354.33 ft / 354.33 ft) x 35.43 ft x (13.45 / 14.19 ft)
(108.00 m / 108.00 m) x 10.80 m x (4.10 / 4.32 m)
Armament:
4 - 5.00" / 127 mm 50.0 cal guns - 66.16lbs / 30.01kg shells, 180 per gun
Quick firing guns in deck mounts, 1910 Model
2 x Twin mounts on centreline ends, evenly spread
4 - 3.94" / 100.0 mm 50.0 cal guns - 32.30lbs / 14.65kg shells, 180 per gun
Quick firing guns in casemate mounts, 1910 Model
4 x Single mounts on sides, evenly spread
4 hull mounts in casemates- Limited use in all but light seas
8 - 1.46" / 37.0 mm 50.0 cal guns - 1.64lbs / 0.74kg shells, 350 per gun
Quick firing guns in deck mounts, 1910 Model
4 x 2 row twin mounts on centreline, evenly spread
Weight of broadside 407 lbs / 185 kg
Armour:
- Gun armour: Face (max) Other gunhouse (avg) Barbette/hoist (max)
Main: 5.91" / 150 mm - -
2nd: 5.00" / 127 mm - -
Machinery:
Oil fired boilers, steam turbines,
Geared drive, 2 shafts, 33,897 shp / 25,287 Kw = 33.00 kts
Range 4,000nm at 12.00 kts
Bunker at max displacement = 377 tons
Complement:
142 - 185
Cost:
£0.221 million / $0.886 million
Distribution of weights at normal displacement:
Armament: 72 tons, 3.8%
- Guns: 72 tons, 3.8%
Armour: 62 tons, 3.3%
- Armament: 62 tons, 3.3%
Machinery: 1,027 tons, 54.6%
Hull, fittings & equipment: 385 tons, 20.4%
Fuel, ammunition & stores: 289 tons, 15.3%
Miscellaneous weights: 25 tons, 1.3%
- Hull below water: 25 tons
Overall survivability and seakeeping ability:
Survivability (Non-critical penetrating hits needed to sink ship):
447 lbs / 203 Kg = 7.2 x 5.0 " / 127 mm shells or 0.3 torpedoes
Stability (Unstable if below 1.00): 1.69
Metacentric height 2.5 ft / 0.8 m
Roll period: 9.4 seconds
Steadiness - As gun platform (Average = 50 %): 70 %
- Recoil effect (Restricted arc if above 1.00): 0.16
Seaboat quality (Average = 1.00): 1.12
Hull form characteristics:
Hull has a flush deck,
a normal bow and large transom stern
Block coefficient (normal/deep): 0.390 / 0.403
Length to Beam Ratio: 10.00 : 1
'Natural speed' for length: 21.81 kts
Power going to wave formation at top speed: 66 %
Trim (Max stability = 0, Max steadiness = 100): 63
Bow angle (Positive = bow angles forward): -12.00 degrees
Stern overhang: -3.94 ft / -1.20 m
Freeboard (% = length of deck as a percentage of waterline length):
Fore end, Aft end
- Forecastle: 24.00%, 20.73 ft / 6.32 m, 15.81 ft / 4.82 m
- Forward deck: 28.00%, 15.81 ft / 4.82 m, 12.53 ft / 3.82 m
- Aft deck: 30.00%, 12.53 ft / 3.82 m, 12.86 ft / 3.92 m
- Quarter deck: 18.00%, 12.86 ft / 3.92 m, 13.19 ft / 4.02 m
- Average freeboard: 14.39 ft / 4.39 m
Ship space, strength and comments:
Space - Hull below water (magazines/engines, low = better): 189.5%
- Above water (accommodation/working, high = better): 113.8%
Waterplane Area: 7,968 Square feet or 740 Square metres
Displacement factor (Displacement / loading): 61%
Structure weight / hull surface area: 29 lbs/sq ft or 141 Kg/sq metre
Hull strength (Relative):
- Cross-sectional: 0.44
- Longitudinal: 1.55
- Overall: 0.50
Cramped machinery, storage, compartmentation space
Adequate accommodation and workspace room
Ship has slow, easy roll, a good, steady gun platform
----------
模拟一下， 33节以上，1500T标排！
|
|
